Thin Bezel 55 Inch WebOS TV Tempered Glass WebOS Television Smart Update

Brand Name:	MianHong
Model Number:	W-5503HF-V
MOQ:	300
Price:	Negotiable
Packaging Details:	CARTON BOX GIFT BOX
Payment Terms:	L/C, D/A, D/P, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CCC, CE, SGS, ISO

Features:

WebOS With Various Apps(Prime, Youtube, Netflix),ODM/OEM Available

Model:

W-5503HF-V

Bezel:

Standard,Thin

Operating System:

WebOS

Resolution:

HD,FHD,UHD 4K

Size:

24",32",38",40",43",55",65",75",85"

Glass:

Optional Tempered Glass

Display Type:

LED A+ Screen

Sync Frequency:

50Hz/60Hz

Respone Time:

Color:

Black

Backlight Life:

≥20000hrs

Supply Ability:

2500-3000PCS ONE DAY

Highlight:

Smart Update 55 Inch WebOS TV

Tempered Glass 55 Inch WebOS TV

Tempered Glass WebOS Television

Product Description

LED TV Specification

Model	55''			SMART LED TV 4K Tempered Glass model
Panel						Product Image
Display type	LED A+ screen
Aspect ratio	16:9
Resolution	3840*2160(UHD)
Brightness	245-260d/m2
Respone time	8ms
Sync Frequency	50Hz/60Hz
Backlight life	≥20000hrs
Power to panel	12V@1000mA rms
System&Features						Other Features
TV Standard	PAL, SECAM, NTSC,DVB-T/DVB-T2/DVB-T2S2/ISDB-T/ATSC					HD resolution	480i, 480p, 720p, 1080i, 1080p, 2160P,CEC, ARC(HD1)
Oprating System	webos
CPU	Quad core ARM Cortex-A55 1.9GHz					GPU	800MHz
Bluetooth version	BT5.0,BT2.1					Cabinet /Color	plastic housing/Black/Option
Sound System	BG, DK, I, L, M/N,A2					Type	Frameless Border
POWER TO PANEL	12V@1000mA rms					RJ45 NETWORK	10/100M auto-identification and DHCP
USB FUNCTION	software upgrade, multimedia play					Button Types	Ground Key Interface
Digital TV system	YES					HD resolution	480i, 480p, 720p, 1080i, 1080p
OSD Language	MULTI LUANGUAGE CAN BE CHOICE					Stand base	YES
Power consumption	75W					Wall mount	NO
COAX	PCM/RAW					Main board	TP.SK713S.PC825(T)
Audio Spearker						Accessories
Audio Output	2*8W(8Ω)/2×10W(6Ω)					Remote Control: 1 Battery(set): 1 Stand: 1 User Manual : 1 Screw: 4
Speakers' Qty'	2
Connectors and Terminal Interfaces
RJ45×1
(mini)CVBS/AUDIO IN ×1
HD IN ×3
USB ×2
EARPHONE OUT ×1
COAX /OPTICAL OUT ×1
ATV/DTV ×1
CI 1
Packing Details
Size	Outer Carton Dimensions(cm)			N.W (KGS)	G.W (KGS)	Container Loading Qty(pcs)
	L	W	H			20GP	40HQ
55''	1158	112	698	8.37	11.8	310PCS	750PCS

W-5503HF-V is a 24″ Smart WebOS TV for customers by providing the necessary balanced specifications, in order to fit in kitchen, living room, bedroom at home.

Be Satisfied Better

Grade A LCD Panel

Mianhong always consider using Grade A LCD Panel as default for each product
Grade A Panel has less defective points/pixels, improving display quality

Frameless Screen Design

Up to only 3mm of the width of side frames
Design for eye-tricking viewing

Stable and Slim stands

2 well-designed stands to protect and hold the body of a TV.
Plastic/Metallic, ground stand/wall-mount stand are fully customizable for budget.

2 speaker options

Flexible speaker for different needs.

What is included in the box:

W-5503HF-V
Manual
PowerPlug(Different types supported)
Remote Controller

Model: W-5503HF-V
Brand: MIANHONG/Your LOGO(ODM/OEM)
System: Android 12/13
Panel Size: 24″
Bezel design: Thin, black/Optional Color
Tuner: T2/S2 Others

Backlight: DLED
Resolution: 1920*1080 / 1366*768
Viewing Angle: 178°H/178°V
Color: 1.6M
Brightness: 300cd/m²
Contrast ratio: 3000:1
Response time: 9.5ms

Power: <= 100W
Voltage: 100V-240V AC 60/50Hz
Audio: 8W+8W

Net Weight: 5KG
Gross Weight: 5KG + Level of Safety
Dimension(Without Stand):

Input Interface: (Optional interface based on demands)
Output Interface: Earphone/Audio-OUT/(Optional interface based on demands)
USB Support: Video/Audio
Bluetooth Support: Yes
